Product Summary
The FZT560TA is a SOT223 PNP silicon planar high voltage transistor.
Parametrics
FZT560TA absolute maximum ratings: (1)Collector-Base Voltage VCBO: -500 V; (2)Collector-Emitter Voltage VCEO: -500 V; (3)Emitter-Base Voltage VEBO: -5 V; (4)Peak Pulse Current ICM: -500 mA; (5)Continuous Collector Current IC: -150 mA; (6)Power Dissipation at Tamb=25℃ Ptot: 2 W; (7)Operating and Storage Temperature Range Tj:Tstg -55 to +150 ℃.
Features
FZT560TA features: (1)500 Volt VCEO; (2)150mA continuous current; (3)Ptot = 2 Watt.
