NC7WZU04P6X

dual unbuffered inverter, High Speed Series, unbuffered circuit

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.15~0.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.15~0.20

PartNumber:: NC7WZU04P6X

Brand:: Fairchild Semiconductor - Fairchild | Pack: SC | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Toby's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-03-12

From Other Seller

Part Number:NC7WZU04P6X
US $0.15 - 0.20
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
2DI75D-050A

US $16.00 - 30.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The NC7WZU04P6X is a dual unbuffered inverter from Fairchild’s Ultra High Speed Series of TinyLogic in the space saving SC70 6-lead package. The special purpose unbuffered circuit design is intended for crystal oscillator or analog applications. The device is fabricated with advanced CMOS technology to achieve ultra high speed with high output drive while maintaining low static power dissipation over a very broad VCC operating range. The device is specified to operate over the 1.65V to 5.5V VCC range. The inputs are high impedance when VCC is 0V. Inputs tolerate voltages up to 7V independent of VCC operating voltage.

Parametrics

Absolute maximum ratings:(1)Supply Voltage (VCC): －0.5V to +7V; (2)DC Input Voltage (VIN): －0.5V to +7V; (3)DC Output Voltage (VOUT): －0.5V to +7V; (4)DC Input Diode Current (IIK), VIN < －0.5V: －50 mA; (5)DC Output Diode Current (IOK), VOUT < －0.5V: －50 mA; (6)DC Output Diode Current (IOK), VOUT > 0.5V, VCC = GND: +50 mA; (7)DC Output Current (IOUT): ±50 mA; (8)DC VCC/GND Current (ICC/IGND): ±100 mA; (9)Storage Temperature (TSTG): －65°C to +150°C; (10)Junction Temperature under Bias (TJ): 150°C; (11)Junction Lead Temperature (TL), (Soldering, 10 seconds): 260°C; (12)Power Dissipation (PD) @ +85°C: 180 mW.

Features

Features: (1)Space saving SC70 6-lead package; (2)Ultra small MicroPak leadless package; (3)Unbuffered for crystal oscillator and analog applications; (4)Balanced Output Drive: ±8 mA at 4.5V VCC; (5)Broad VCC Operating Range: 1.65V to 5.5V; (6)Low Quiescent Power: ICC < 1 μA at 5V VCC, TA = 25°C.
