Product Summary

STANLEY

Green 1206 144/148° 1.4 mcd Water clear 2.1 V LED Surface Mount

Mfr Part#: BG1101W-TR
Mounting Method: Surface Mount
Packaging: Cut Tape
Std Packaging Qty: 2,500

The BG1101W-TR is a part of 1101W series LED lamp. It has a operating temperature ranging from -30°C to +85°C.


Parametrics

Applications:

  • Communication Machine

  • Electric Household Appliances

  • Amusement Equipment

  • OA/FA


Features

Features:

  • Outer Dimension: 3.0 x 1.5 x 1.5 mm(LxWxH)

  • Lead–free soldering compatible

  • RoHS compliant

  • Package: 3216 type, Water Clear resin

  • Dominant wavelength:

    • Green : 558nm(BG)

  • Rank grouping parameter: Sorted by luminous intensity per rank taping

  • Assembly method: Auto pic & place machine

  • Soldering methods: Reflow soldering and manual soldering




Diagrams


Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
BG1101W-TR
BG1101W-TR


LED PURE GREEN CLEAR 1206 SMD

Data Sheet

0-1: $0.31
1-25: $0.18
25-100: $0.14
100-250: $0.11
250-500: $0.10
500-1000: $0.08
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
BG1101F-TR
BG1101F-TR


LED PURE-GREEN CLEAR RT ANG SMD

Data Sheet

0-1: $0.29
1-25: $0.18
25-100: $0.15
100-250: $0.13
250-500: $0.11
500-1000: $0.08
BG1101W-TR
BG1101W-TR


LED PURE GREEN CLEAR 1206 SMD

Data Sheet

0-1: $0.31
1-25: $0.18
25-100: $0.14
100-250: $0.11
250-500: $0.10
500-1000: $0.08
BG1102W-TR
BG1102W-TR


LED PURE GREEN CLEAR 1206 SMD

Data Sheet

0-1: $0.32
1-25: $0.19
25-100: $0.15
100-250: $0.11
250-500: $0.10
500-1000: $0.08
BG1111R-TR
BG1111R-TR


LED PURE GREEN CLEAR 1206 SMD

Data Sheet

0-1: $0.27
1-25: $0.17
25-100: $0.14
100-250: $0.12
250-500: $0.10
500-1000: $0.08
BG1112H-TR
BG1112H-TR


LED PURE GREEN 0805 SMD

Data Sheet

0-4000: $0.05
4000-8000: $0.05
8000-12000: $0.05
12000-28000: $0.04
BG1111C-TR
BG1111C-TR


LED PURE GREEN 0603 SMD

Data Sheet

0-1: $0.32
1-25: $0.18
25-100: $0.13
100-250: $0.09
250-500: $0.08
500-1000: $0.06
